Trenton W Posted Wednesday at 06:30 PM Report Posted Wednesday at 06:30 PM Hello all, I am a soon to be Mooney M20C owner, (picking it up Friday). It is in desperate need of some panel upgrades. I am considering a GNX 375 for the ads-b/transponder and GPS. However, it currently has a STEC-30 I would like to keep for now. Does the GNX 375 have the capability to connect directly to the STEC-30 or is a G5 required also, or another converter of some sort? It is currently connected to an old Garmin 150xl with GPSS adaptor. Thank you! -Trent
Yetti Posted Wednesday at 07:06 PM Report Posted Wednesday at 07:06 PM I just had that quoted. Stec 30 is in plane. The work was for Install two 275s and a GNX375 From the shop "I am not aware of any additional adapter needed for the STEC30. We have done a few and only time an adapter is needed is with the G5s. "
Trenton W Posted Wednesday at 08:38 PM Author Report Posted Wednesday at 08:38 PM 1 hour ago, Yetti said: I just had that quoted. Stec 30 is in plane. The work was for Install two 275s and a GNX375 From the shop "I am not aware of any additional adapter needed for the STEC30. We have done a few and only time an adapter is needed is with the G5s. " How much was that quote roughly? I haven't got an install quote yet. The 275s are certainly what I would want but they are proud of them!
Ragsf15e Posted Thursday at 04:07 AM Report Posted Thursday at 04:07 AM 9 hours ago, Yetti said: I just had that quoted. Stec 30 is in plane. The work was for Install two 275s and a GNX375 From the shop "I am not aware of any additional adapter needed for the STEC30. We have done a few and only time an adapter is needed is with the G5s. " @Trenton W @Yetti sorry, I should read better. If you have a gpss, it should work. What is it currently using as a heading bug ? Do you have an hsi? Gpss will translate from the -375 to the stec.
Trenton W Posted Thursday at 12:54 PM Author Report Posted Thursday at 12:54 PM 8 hours ago, Ragsf15e said: @Trenton W @Yetti sorry, I should read better. If you have a gpss, it should work. What is it currently using as a heading bug ? Do you have an hsi? Gpss will translate from the -375 to the stec. 1
Ragsf15e Posted Thursday at 03:22 PM Report Posted Thursday at 03:22 PM 2 hours ago, Trenton W said: You’ll need to get a real avionics place to be sure, but the gpss should be fine between the-375 and the stec30.
LANCECASPER Posted Thursday at 03:34 PM Report Posted Thursday at 03:34 PM 21 hours ago, Trenton W said: Hello all, I am a soon to be Mooney M20C owner, (picking it up Friday). It is in desperate need of some panel upgrades. I am considering a GNX 375 for the ads-b/transponder and GPS. However, it currently has a STEC-30 I would like to keep for now. Does the GNX 375 have the capability to connect directly to the STEC-30 or is a G5 required also, or another converter of some sort? It is currently connected to an old Garmin 150xl with GPSS adaptor. Thank you! -Trent The STEC is a rate based autopilot and gets its info from the STEC turn coordinator so you don't need a G5. The heading bug you have should still work.
