I've experienced both. First it was a VR (I have the old electrodelta VR802). Luckily it failed on the ground. It was removed and repaired. The technician that worked on it said it was a bad resistor (or something like that) very easy and cheap to repair. E few months ago I had the alternator go out right after takeoff returning home from an airport about 250nm away. After takeoff it went offline. I tried the checklist items without success. I was taking off an airport with absolutely no resources for a repair so I elected to continue flight on battery power to a larger field 20mins away. I informed ATC I could lose radio contact any minute and pushed on. It was a national holiday, so I had to find an FBO to park, find and A&P to see the plane next morning and get on an airline flight back home :-( It wasn't before a whole week I could go back to get the plane. It turned out to be broken field wire. We ended up redoing all connections to make them firmer.

Hello everyone, I have seen some pictures of some modern looking rocker switches but I can't seem to find out if they are approved for use in certificated airplanes. I've found some models on aircraft Spruce but they all seem to be for experimentals. Can anyone point me to the correct brand/models? I'd love to have modern looking switches to replace my M20J rockers.

Yes. There are many features it adds which the old non-WAAS GNS430 doesn't have: Holds Parallel track Airways Waypoint Alt constraints VNAV integration G3X can send Flt Plan to the GPS Smart Glide Plus the added benefit of ADSB in/out for the GNX375.

Nope... I have the old grumpy non WAAS GNS430

Very nice upgrade. Very similar to what I did with my M20J. I didn't have the cash to put in a new GPS, though. Now I am contemplating purchasing an used GNX375 to have a modern GPS, ADSB and retire my old King KT76A transponder.

Older Voltage regulators like the one I have in my 1990 J are actually not very complex equipments. They're circuit boards with very simple and easy to find components like resistors, capacitors, etc. An electronic technician can easily work with them to troubleshoot. Most of the times (not always) electrical problems are easier to pinpoint than mechanical. You can get point to point readings with a multimeter to isolate where some faults are coming from.

I've had this problem. In my case it was the VR802 voltage regulator. A technician removed it and changed a fried component (very quick diagnostic and repair) and bench tested it. It has worked great ever since.

I have had a back-an-forth with Mooney support as well. My rudder is out of specs. I discovered it has been painted in the past without stripping the old paint and that is what is probably making it too heavy. I'll have to strip the paint, repaint it and redo the static balance check

+1 here. I would love the improved fuel consumption and cleaner burn (higher spark voltage) of the EIS. However, Electroair's website is kind of unclear about the single-drive dual Bendix magneto replacement. Although their engine AML says that Lycoming IO-360-A3B6D is an approved model, it lists the EIS 41000 as the installation model. However, their website shows the EIS-42000DM as the "correct" model ("The EIS-42000D Electronic Ignition Kit is a fully STC'd kit to replace the Bendix single drive, dual magneto with a complete, DUAL ELECTRONIC ignition.") Other things that caught my attention: all 41000 models have links to AML, installation instructions, AFM Supplement, etc. The 42000 does not. Their STC page does not show the 42000 anywhere. I contacted their distribution partner in Brazil and they said that their STC for the Bendix dual mag is not yet validated by ANAC (Brazilian civil aviation authority), but I am thinking that their FAA STC hasn't yet gone through for that specific model... or am I missing something here?

I have downloaded and have read the manual. The only question I have - and I want to check the mechanics are doing it right - is where along the length of the rudder is the correct spot put the scale support point (in red in the image below).

Hello everyone. I am having my 1990 M20J go through the 2900lbs gross weight increase procedure as per SL92-1. The shop is doing the rudder balance check as directed by SB-M20-252 but the rudder seems to be out of specs: the measured moment is not within limits and we'd need to add weight to the rudder horn counterweight. As we're discussing the best approach to fall within limits, I am suspecting the plane has been painted with a heavy coat in the past (before I purchased it) and it is affecting the surface weight. However, since I live in Brazil and there are very few Mooneys around here, I suspect there is also a possibility that the A&Ps at the shop aren't measuring the distance to calculate moment at the correct spot. Consequently, I'd like to ask members here if someone might have pictures of this balancing procedure and where they actually measured the underbalance weight. Thanks!

Hello 1 - lean so much as the engine will not develop meaningful RPM if you try to apply takeoff power. This will have two effects: lean operation at low power and protects you from inadvertently trying to takeoff forgetting to enrichen the mixture. 2 and 3 - Follow the most recent manufacturers' recommendations. For most of the Lycoming direct drive engines it will be Service Instruction SI-1132B. It says to do the run-up at 50-65% power and Best Power mixture. For most engines it will be higher than the POHs 2000 RPM. 4 - Takeoff is when we get as close to maximum rated power as possible. Aviation engines have large compression rates and will need excess fuel to allow for thermal protection against detonation. So it is NOT a good idea to takeoff very lean. Aspirated engines should be running at full rich unless density altitude is playing a role (about > than 3000ft you should find best power). Turbocharged engines will always "think" they're at sea level so you always takeoff with mixture full rich, unless your POH tells you otherwise. 5 - If you are looking for operating LOP the best technique is Mike Busch's big mixture pull until noticing a drop in power output. Then enrichen slowly to peak EGT, and then stablish the regimen you wish (LOP or at peak). After you do it a few times and establish your LOP operation you will start to notice the LOP fuel flow for different altitudes, as EGT will vary depending on atmospheric conditions and RPM settings, and relate it to a TAS. After a while you'll be able to do the big mixture pull, feel the engine loose a little power and then enrichen to a known fuel flow while crosschecking with airspeed. I my plane (IO-360-A3B6D) that equates to about 8.8 to 9.2gph up until 5500 feet and 7.7 to 8.2 gph at 11,000. For me it leads to a 139kts TAS. 6 - It really depends on your operation and how fast you wish to climb. You CAN climb LOP. However it will require monitoring temps more closely as your mixture will become richer as atmosphere becomes thinner. ROP climb will yield more power and a quicker climb. 7 - It varies. How high and how lean were you in cruise? If you were very high and running LOP your engine will show signs of over lean mixture as you descent. 8 - I have it in my After landing checklist: mixture ...... LEAN. Same as after start.

I believe that's the correct approach to take. However, as I explained before, I bought the Mooney and took it straight to the avionics shop (my first experience as an owner). I approached it as I would a very well recommended doctor for a surgery: I thought I needed not to know the tecnical details about the procedure to be executed. Certainly now, I see it is very different with aircraft maintenance.

Very interesting (negatively, of course) to see many similar accounts. Indeed, there seems to be a repeating pattern here. Unfortunately, Garmin doesn't publicly offer installation manuals or STC supplements unless you're an authorized dealer. So we actually have no way of knowing in advance what and how things will be done to get minimally involved.

It is accessible from under the panel or behind the center pedestal? Anyone has pictures? I can't seem to find this switch or procedure in the Service Manual.
